UV Sterilizer(Digital)-Ultra Fresh
Introducing Ultraviolet Sterilizer Dewfresh a Product manufactured from state of the art technology for sterilizing the air within
the sterilization chamber. An ultraviolet ray is a band of light with short wavelengths from 2000 to 2950 angstrom units which
possess the greatest germicidal effects of all ultraviolet wavelengths, particularly the wavelengths of 2537 angstrom units. It is
extensively used to destroy airborne bacteria, virus, mould pores, etc.
How Does it Work:
Ultraviolet Sterilizer can be kept on even during the operations as special measures are taken to save against direct radiation.
This unit can be mounted on wall, kept on the table or kept at a suitable place.
The TUV lamps have germicidal effect for killing and inactivating bacteria, viruse and other primitive organisms. The impurities
and bacteria are floating in the air. In order to sterilize and purify the air, sterilization chamber is provided which has an
arrangement to draw the impure air from the top filter it with dust filter then with 15 micron fine filter, then air passes through
carbon filter (Optional) and finally sterlizes with Ultraviolet Radiation and then releases the pure clean air it into the room.
Special measures are taken to protect against direct radiation.
What is UV Sterilization
U V ray penetrates direct into bacteria and raises various kinds of biochemical reaction itself Then bacteria dies out or falls into a functional disorder. Especially UV rays strike directly bacteria’s
DNAand have a fatal influence on it. These UV rays work directly on most bacteria’s DNAsequences and raise disorder itself, then inactivates bacteria’s cell perfectly.
Five Steps of Sterilization
Step-I Dust Filter: - large particles of dust such as strands and hairy-dusts are filtered at this stage.
Step-II 15 Micron Filter:- Minute particles floating in the air are filtered from this filter.
Step-III Carbon Filter (Optional):- Thanks to the functions of strong deodorization and decomposition.The carbon filter removes tobacco smoke and smell of food and most odours.
Step-IV U V Filter:- Equipped with two 8 watt. U.V. Lamp effectively sterilizes the air.
Step-V Lonizer (Optional):- This Negative lon generator generates large quantities of negative lons, thus it feels fresh and comfortable.
Ultra Violet Sterilizer can be effectively installed at different places
At medical site like Operation Theatre. ICCU, ICU, NICU. Post Operative Wards, Trauma Wards, Mortuary, etc. Suitable for small Laboratories where bacteria free air is desired.
At homes in a closed room especially for allergic patients suffering from Respiratory diseases like Asthma. Can also be used for the patients suffering from AIDS.
Optional
Digital Timer-Dual Digital Timer for display of total time and lapse time for the sterilizer which can also be adjusted according to the particular need. Remote Control.
Technical Specifications
Dimensions : H 13. 0 IN x W 14.5 IN x D 9.5 IN
Gross Weight : 4. 00 Kg. (Approx)
Voltage Required : 230V AC 50Hz.
Power Consumption : 50W
Fuse : 350MA
