- High Frequency Auto Programmable X-Ray Systems
- Best Suited for Bed Side X-Ray & Trauma Care.
- Spring Based Counter Balanced Stand for easy mobility from ward to ward within Hospital.
- Soft Touch Key Pad with Automatic Selection of kVp, mA and mAs for each Body Part.
- Re programmable options for new selection of kVp, mA and mAs at customer's Place.
- Microprocessor based X-Ray Exposure Control with Microprocessor based Overload Protection for Better Tube Safety
TECHNICAL SPECFICATIONS
|
Parameter |
Item Code: IS1560 |
Item Code: IS1570 |
Item Code: IS1580 |
|
Tube Current (Max) |
60mA |
100mA |
100mA |
|
Radiological Ratings |
45-100kVp |
45-100kVp |
45-100kVp |
|
Power |
2.4kW |
3.5kW |
5.0kW |
|
Tube Type |
Stationary Anode |
Statiionary Anode |
Rotating Anode |
|
Power Supply |
230V,AC,5Hz,15 Amps with line regulation of +/-10% Line Resist:<0.4 ohms. |
230V,AC,5Hz,15 Amps with line regulation of +/-10% Line Resist:<0.4 ohms. |
230V,AC,5Hz,15 Amps with line regulation of +/-10% Line Resist:<0.4 ohms. |
|
Options |
Compatible Table |
|
Mobile Unit |
Horizontal Table |
|
Floor to Ceiling Unit |
Manual Tilt Five Position Table |
|
|
Floating Table Top Table |
|
Item Code |
IS1560 |
|
IS1570 |
|
|
IS1580 |
